产品描述
|
三缸泵系列技术参数Technical Parameters Of Three Cylinder Pump Series |
||||||
|
型号 |
吸程 |
压力 |
柱塞数x直径x冲程 |
转速 |
马力 |
包装尺寸 |
|
YT-26PD |
14-22m |
20-45MPa |
3x22x16mm |
800-1200rpm |
2-3HP |
35X29X33cm |
|
YT-26ZL |
14-22m |
20-45MPa |
3x22x16mm |
800-1200rpm |
2-3HPHP |
35X29X26cm |
|
YT-30PD |
33-44m |
20-45MPa |
3x30×20mm |
800-1200rpm |
3-5HP |
39X30.5X33cm |
|
YT-30ZL |
33-44m |
20-45MPa |
3x30x20mm |
800-1200rpm |
3-5HP |
37X36X30cm |
|
YT-G25 |
22m |
40MPa |
3x25x16mm |
800-1200rpm |
2-3HP |
30X20X30cm |
|
YT-80 |
58-68m |
50-80MPa |
3x33.5x26mm |
800-1200rpm |
5-7.5HP |
44.5X34X45cm |
|
YT-120 |
103-116m |
20-120MPa |
3x38x38mm |
800-1200rpm |
5-9HP |
50X36.5X52cm |
